7005 aluminum plate

7005 aluminum plate, American deformed aluminum and aluminum alloy.The strength of the 7005 is higher than that of the 7003 alloy, which has good welding performance and can be strengthened by heat treatment.

Alloy: 7005

Temper:  T6, T651, T62, T652, T76, T74,T7451, T73, T7351

Stretching capacity: 300000m2, supposed width is 2000mm, then the maximum thickness is 150mm.

Thickness: 1.0mm--300mm

With: 500mm--3000mm

Length: 1000mm--12000mm

Surface: Mill finish, Bright finish, paper interleaved, one side film, both sides film.

haracteristics and applications
7005 aluminum alloy extruded material, often used in the manufacture of both high strength and high fracture toughness welded structures, such as trusses, rods, vessels for transport vehicles;Large heat exchangers and components that cannot be soldered after welding;It can also be used to make sports equipment such as tennis rackets and softball bats.

Chemical composition
Aluminum Al(minimum) : margin
7005 aluminum silicon Si: ≤0.35
Iron Fe: 0.40 or less
Copper Cu: 0.10 or less
Manganese Mn: 0.20 ~ 0.7
Magnesium Mg: 1.0 ~ 1.8
Chromium Cr: 0.06 ~ 0.20
Zinc and zinc: 4.0 ~ 5.0 [1]
Zirconium Zr: 0.08 ~ 0.20

Physical properties
Material status of 7005 aluminum plate: T1, T3, T4, T5, T6, T8
Manufacturing method: drawing .

Mechanical properties:
State tempert4: tensile strength uts324, specified non-proportional elongation stress yield215, elongation elongation11, conductivity 40-49
Aluminum alloy material 6061,7005,7075 difference
Pure aluminum is soft, but the alloy is hard.Various alloys can be made by adding different metals. 6061,7005,7075 are all aluminum alloy models.
6061 aluminum plate is the most common aluminum, light, good strength, and affordable.
7005 aluminum plate is light aluminum, the strength is not as strong as 6061, but much lighter, the price is also high.
7075 aluminum plate is the lightest and the strongest aluminum, the price is also super expensive!The 7075 is as strong as steel.
